Solar Street Light

Series No.: SM-S015

  • SM-S015 series of all-in-one solar led street light, which have high efficiency monocrystalline silicon solar panel, lithium iron phosphate battery with more than 5 years’ lifespan, intelligent solar controller with time control, dimming control and automatic energy-saving control mode and PIR sensor, are widely used in the followings:
    Urban roads, local roads & rural roads
    Industrial park factory & factory roads
    Public garden & residential area
    Villa and private residence
    Car parking
    Shopping center & square
Catalog Install Manual
Get A Free Quote
  • s02 icon1
    Patented Products
  • s02 icon2
    High Brightness
  • s02 icon3
    High Efficacy
  • s02 icon5
    Good Heat Dissipation
  • s02 icon6
    ECO Friendly
  • s02 icon7
    Easy Install

Stable and Genuine Properties

Technical Specifications

  • Model No. Watt(W)  Main Parameter
     SM-S015-10W 10W Material: aluminium Condition Temperature:  -20-50℃
    LED Qty:50pcs  Bridgelux/CREE 3030 Work Humidity: ＞95%
    Power: 10W CRI: Ra>80
    Input Voltage:DC12V Controller efficiencyr: ≥0.90
    Controller:20W Lens angle:70*140º
    Batteries: 8AH Work time:0-12H
    Solar Panel: 17WP Waterproof: IP65
    Short Current: ＜5mA  NW: 6.5KG     GW: 8KG
    Lighting effect:150LM/W Size.: 478*315*70mm
    Rainy days:2-3days     Charging time:8-10hrs Package size:600*410*155mm 1PCS/CTN
    Height of installation:3-4M ; Install distance:  10-12M Light pole diameter＜60mm
  • Model No. Watt(W)  Main Parameter
     SM-S015-15W 15W Material: aluminium Condition Temperature:  -20-50℃
    LED Qty:50pcs  Bridgelux/CREE 3030 Work Humidity: ＞95%
    Power: 15W CRI: Ra>80
    Input Voltage:DC12V Controller efficiencyr: ≥0.90
    Controller:20W Lens angle:70*140º
    Batteries: 10-11AH Work time:0-12H
    Solar Panel: 26WP Waterproof: IP65
    Short Current: ＜5mA  NW: 7.5KG     GW: 9KG
    Lighting effect:150LM/W Size.: 688*315*70mm
    Rainy days:2-3days     Charging time:8-10hrs Package size: 880*410*155mm  1PCS/CTN
    Height of installation:3-4M ; Install distance:  10-12M Light pole diameter＜60mm
  • Model No. Watt(W)  Main Parameter
     SM-S015-20W 20W Material: aluminium Condition Temperature:  -20-50℃
    LED Qty: 50pcs  Bridgelux/CREE 3030 Work Humidity: ＞95%
    Power:20W CRI: Ra>80
    Input Voltage:DC12V Controller efficiencyr: ≥0.90
    Controller:20W Lens angle:70*140º
    Batteries: 10-11AH Work time:0-12H
    Solar Panel: 40WP Waterproof: IP65
    Short Current: ＜5mA NW:13.6KG     GW:15.6KG
    Lighting effect:150LM/W Size.: 688*315*70mm
    Rainy days:2-3days     Charging time:8-10hrs Package size: 880*410*155mm  1PCS/CTN
    Height of installation:4-5M ; Install distance:  18-20M Light pole diameter＜60mm
  • Model No. Watt(W)  Main Parameter
     SM-S015-40W 40W Material: aluminium Condition Temperature:  -20-50℃
    LED Qty: 96pcs  Bridgelux/CREE 3030 Work Humidity: ＞95%
    Power:40W CRI: Ra>80
    Input Voltage:DC12V Controller efficiencyr: ≥0.90
    Controller: 20W Lens angle:70*140º
    Batteries:18-22AH Work time:0-12H
    Solar Panel: 52WP Waterproof: IP65
    Short Current: ＜5mA NW:13.6.KG    GW:15.6KG
    Lighting effect:150LM/W Size.:828*443*70mm
    Rainy days:2-3days     Charging time:8-10hrs Package size:1020*550*155mm 1PCS/CTN
    Height of installation: 4-5M ; Install distance:  20-25M Light pole diameter＜60mm
  • Model No. Watt(W)  Main Parameter
     SM-S015-60W 60W Material: aluminium Condition Temperature:  -20-50℃
    LED Qty:100pcs  Bridgelux/CREE 3030 Work Humidity: ＞95%
    Power:60W CRI: Ra>80
    Input Voltage:DC12V Controller efficiencyr: ≥0.90
    Controller:60W Lens angle:70*140º
    Batteries: 24-28AH Work time:0-12H
    Solar Panel: 95WP Waterproof: IP65
    Short Current: ＜5mA GW:14.3KG      NW:16.3KG
    Lighting effect:150LM/W Size: 1162*553*70mm
    Rainy days:3-5days     Charging time:8-10hrs Package size:1250*650*155mm  (Lamp)
    Height of installation:5-6M ; Install distance:  20-25M Light pole diameter＜78mm
  • Model No. Watt(W)  Main Parameter
     SM-S015-80W 80W Material: aluminium Condition Temperature:  -20-50℃
    LED Qty:144pcs  Bridgelux/CREE 3030 Work Humidity: ＞95%
    Power:80W CRI: Ra>80
    Input Voltage:DC12V Controller efficiencyr: ≥0.90
    Controller:60W Lens angle:70*140º
    Batteries:30-33AH Work time:0-12H
    Solar Panel:120WP Waterproof: IP65
    Short Current: ＜5mA GW:15.8KG     NW:17.8KG
    Lighting effect:150LM/W Size: 1308*553*70mm
    Rainy days:2-3days     Charging time:8-10hrs Package size：1410*650*155mm     (Lamp)
    Height of installation:5-6M ; Install distance:  20-25M Light pole diameter＜78mm
  • Model No. Watt(W)  Main Parameter
     SM-S015-100W 100W Material: aluminium Condition Temperature:  -20-50℃
    LED Qty:144pcs  Bridgelux/CREE 3030 Work Humidity: ＞95%
    Power:100W CRI: Ra>80
    Input Voltage:DC12V Controller efficiencyr: ≥0.90
    Controller:60W Lens angle:70*140º
    Batteries:52AH Work time:0-12H
    Solar Panel:150WP Waterproof: IP65
    Short Current: ＜5mA GW:16.2KG      NW:18.5KG
    Lighting effect:150LM/W Size: 1478*553*70mm
    Rainy days:3-5days     Charging time:8-10hrs Package size:1570*650*155mm   (Lamp)
    Height of installation:6-7M ; Install distance:  25-30M Light pole diameter＜78mm
